Advanced Qh-Mbr Aquarium Filter System for Crystal Clear Water

1 / 5

Advanced Qh-Mbr Aquarium Filter System for Crystal Clear Water

Certification:	ISO9001, RoHS, CE
Salt Rejection Rate:	98.0%
Application:	Industry

Send Inquiry

Product Description

Basic Information

Model NO.:

QH-MBR

Capacity:

400 Gallon

Product Name:

MBR System

Method:

Physical Treatment

Usage:

Industrial, Agriculture, Hospital

Membrane Material:

PVDF (Graphene Modified)

Nominal Pore Size:

0.2µM

Flow Direction:

Outside-in

Membrane Type:

Hollow Fiber

Housing:

PVC-U

Product Description

MBR SYSTEM
The MBR system combines biological treatment with membrane filtration technology to deliver superior wastewater treatment solutions. This advanced membrane bioreactor system features high-efficiency solid-liquid separation, compact design, and automated operation for various industrial and municipal applications. The system ensures consistent effluent quality, reduced footprint, and enhanced nutrient removal while maintaining operational flexibility. Ideal for facilities seeking sustainable water treatment, space optimization, and regulatory compliance with minimal maintenance requirements.

Detailed Photos

SUPERIOR FILTRATION PERFORMANCE

Advanced membrane technology delivers exceptional water quality output, eliminating suspended solids and producing crystal-clear effluent.

SPACE-SAVING DESIGN

Compact footprint reduces installation area requirements significantly compared to traditional systems.

OPERATIONAL EFFICIENCY

Automated control systems minimize manual intervention while maximizing treatment capacity and reducing costs.

Technical Parameters

Core Specifications
Membrane Main Material	PVDF (Graphene Modified)
Nominal Pore Size	0.2µm
Max. Transmembrane Pressure	0.5Bar
Max. MLSS	10g/L
Filtration Flux	10~60 LMH
Fiber Inside/Outside Diameter	1.0mm / 2.0mm
Backwash Type	Air and Water
PH Range (Operation)	2~12
Max. Operation Temperature	40 Degree Celsius
Backwash Water Flux	60~100 LMH

ENHANCED TREATMENT EFFICIENCY

Achieves superior pollutant removal rates while maintaining consistent performance across varying load conditions.

FLEXIBLE SCALABILITY

Modular design allows seamless capacity expansion to accommodate future growth without major infrastructure modifications.

SIMPLIFIED MAINTENANCE

User-friendly design features easy-access components and automated cleaning cycles that extend membrane lifespan.

Frequently Asked Questions

Q1: Are you a manufacturer or a trader? A: We are a manufacturer integrating industry and trade, focusing on professional wastewater treatment solutions.

Q2: Do you support product customization? A: Yes, we support on-demand customization including LOGO, color, and appearance size to meet specific project requirements.

Q3: What payment methods are accepted? A: We support multiple payment methods including T/T, Western Union, Paypal, and cash. Details can be negotiated during the order process.

Q4: How do you handle transportation and shipping? A: We choose the most appropriate mode of transportation (sea, air, or land) based on the volume and destination, or according to your specific requirements.

Q5: How can I receive an accurate quotation for my project? A: Please provide your specific demand information, site conditions, and required capacity. We will customize a solution and provide a detailed price.

Q6: What is the lifespan and maintenance requirement for the MBR membrane? A: Our PVDF Graphene Modified membranes are designed for longevity. With automated CIP and backwashing systems, maintenance is simplified to ensure optimal performance over many years.
